Dereeler: Accu-Feed HPD
The Accu-Feed HPD High Performance Dereeler is similar to the Accu-Feed LTD in design and function. However, the HPD can handle a much larger spool as well as heavy gauge materials. A larger dancer arm, stronger drive transmission and revised part path eliminates reverse-bending during the feed process, which is ideal for olefin, Teflon®, and heavy gauge materials.
Product Details
Key Features
- Designed for high-volume, critical tolerance manufacturing
- Precision ball-bearing construction for low dancer arm friction
- Torque-limited for safety
- Communicates with Accu-Cut machines
- Incorporates static-reducing technology for cleanliness
Specs
- Speed: 1400 rpm
- Standard OD: 0.25 in (6.4 mm)
- Maximum Spool Diameter: 17.75 in (0.45 m)
- Maximum Spool Width: 10 in (0.25 m)
- Maximum Spool Weight: 12 lb (5.4 kg)
- Power: 100-240 V at 50/60 Hz
- Dimensions: 31 in x 34 in x 37 in (79 cm x 86 cm x 94 cm)
- Weight: 60 lb (27 kg)
