The CR-240-SA Stent Crimping Machine is developed for the crimp and transfer of self-expandable stents into delivery systems in a single, controlled process. It accommodates stents up to 200 mm in length with a maximum diameter of approximately 30 mm, supporting consistent handling of larger, more complex devices.
Key Features
- Integrated dual camera system for process monitoring
- Servo-controlled stent crimping head with Zero Gap technology
- Exchangeable pusher rods and delivery system holders for various stent diameters
- 15.5” user interface with recipe control for process setup
- Built to a high-quality standard for a stable, robust design with minimal cost of ownership
- One-point automatic diameter calibration for quick system setup
- Calibration completed in seconds
- Full process data logging to the internal PC with transfer available via USB for analysis
Technical Specs for the CR 240-SA Stent Crimping Machine
Stent crimping length | 240 mm head. Maximum 200 mm length stents |
Stent type | Self-expandable stents (also for covered stents) |
Maximum diameter loading | 30 mm (optionally larger sizes possible) |
Maximum opening crimp head | 35 mm |
Minimum closing diameter | 0.1 mm (software limit) |
Crimp head control | Servo controlled position / force |
Diameter accuracy | +/- 0.02 mm @ 100 N |
Maximum crimp force | 1000 N radial. Dynamic Diameter Compensation possible |
Crimping speeds | 0.1 mm/s – 10 mm/s |
Maximum transfer force | 200 N with loadcell measurement on the pusher |
Stent loading | Manual (with optional aid of two microscope cameras) |
GUI | 15.5” colour touch panel |
Control software | Zoomable process graphs Recipe based Password levels (operator, engineer, calibrator) Data logging with USB transfer possibility |
Ethernet | 2x |
USB | 2x |
Required air pressure | 7 bar minimum |
Power supply | 115 / 240 VAC / 0.5 kW |
Safety systems | Covers with coded magnets and safety PLC system and double hand control system. |
